Standards of Bridge Cranes

Bridge cranes are our important mechanical products. After purchase and installation, we must pay attention to the acceptance. Nybon Machinery reminds everyone of the acceptance criteria

The acceptance criteria for the traveling beams of single-beam bridge cranes are mainly as follows:

1) The coordination of the whole crane and the factory building, as well as the coordination of the trolley and the bridge should be appropriate. The cooperation between the trolley and the bridge is mainly: the trolley gauge (the horizontal distance between the center planes of the wheels) and the trolley gauge on the bridge should be the same; secondly: the buffer on the trolley and the position of the stopper on the bridge should match well , The striker on the trolley and the travel limit switch on the bridge should be matched properly. The plane layout of the trolley should be compact and the height should be small, so that the height of the crane can be reduced accordingly, thereby reducing the height of the factory building.

2) The arrangement of the mechanism on the trolley and the coordination requirements between the parts in the same mechanism are appropriate. The distance between the lifting mechanism and the trolley operating mechanism should not be too small, otherwise the maintenance is inconvenient, or the trolley frame is difficult to design; but it should not be too large, otherwise the trolley will not be compact.

3) The wheel pressure distribution of the trolley wheels must be uniform. And it is required to obtain the smallest wheel, axle and bearing box size, and make the crane bridge main beam receive a uniform load. Generally, the maximum wheel pressure should not exceed 20% of the average wheel pressure.

4) The mechanism on the trolley frame should match the trolley frame properly. In the design principle, we should focus on the mechanism, and try to use the trolley to match the mechanism; at the same time, the layout of the mechanism should be as convenient as possible for the design and manufacture of the steel structure. Because the trolley frame is to install and support the lifting mechanism and the trolley operating mechanism, the trolley frame should be designed in accordance with the requirements of the lifting and operating mechanism. However, the layout of the mechanism should also be matched with the small The design of the frame makes it simple, reasonable and easy to manufacture.

Remarks: In addition to meeting the above conditions, the standards of the local quality and technical supervision bureau must be met to be qualified.
